Specifications

Previous

Amplifier type:  Stereo Power amplifier

Chassis:  Single

Dual Mono:  Shared Power Supply / Transformer

Harmonic Structural Integrity:  Yes - now with Advanced Harmonic Spectrum

Voltage gain:   32 dB UnBalanced / 30 dB Balanced

175S Rated power: 2, 4, 8Ω , 1kHz, 220 VAC*:  650, 350, 175 W

175S HP Rated power: 2, 4, 8Ω , 1kHz, 220 VAC*:   750, 475, 250 W

175S 20th Anniversary Limited Edition Rated power: 2, 4, 8Ω , 1kHz, 220 VAC*:   750, 475, 250 W

S/N Ratio reference to 10 W*:   -94 dBA

S/N Ratio reference to rated output*:    -115 dBA

Frequency response:   3 to 200 000 Hz ± 3dB

THD + N @ 5 W 20-20K:   < 0.10%

THD + N @ 10 W:  < 0.08%*

THD + N @ 175 W:   < 0.25%*

IMD SMPTE @ 10W:  < .05%

Crosstalk @ 1kHz:  < -100db

Maximum output current per channel, 1kHz, 2 Ohm:  20A peak:  20 KΩ  / 33KΩ

175S Damping factor*:  50

175S HP Damping factor*:  100

175S 20th Anniversary Limited Edition Damping factor*:  100

175S MSRP (usd):  No longer in production

175S HP MSRP (usd):  No longer in production

175S 20th Anniversary Limited Edition MSRP (usd):  $112,750 excluding any Duties or VAT

Weight per unit:  118 lbs / 53.5 kg

Shipping weight in custom road case:  148 lbs / 67.2 kg

Dimensions:  19.5” W x 28” D (including connectors) x 9.5” H (including top ventilation)

* : @ 8 Ohm, 1kHz
