Specifications

Previous

Amplifier Type:  Mono Block Power Amplifier

Chassis:  Single

Dual Mono:  Yes - Separate Channel per Chassis

Harmonic Structural Integrity:  Yes - now with Advanced Harmonic Spectrum

Voltage gain:  32 dB Unbalanced / 30 dB Balanced

350M  Rated power: 2, 4, 8Ω , 1kHz, 220 VAC*:  1400, 700, 350 W

350M HP Rated power: 2, 4, 8Ω , 1kHz, 220 VAC*:  1500, 950, 500 W

350M 20th Anniversary Limited Edition Rated power: 2, 4, 8Ω , 1kHz, 220 VAC*:  1500, 950, 500 W

S/N Ratio reference to 10 W*:  -94 dBA

S/N Ratio reference to rated output*:  -115 dBA

Frequency response:  3 to 200 000 Hz ± 3dB

THD + N @ 5 W 20-20K:  < 0.05%

THD + N @ 10 W:  < 0.04%*

THD + N @ 350 W:  < 0.17%*

IMD SMPTE @ 10W - 100W:  <.01%-.02%

Maximum output current per channel, 1kHz, 2 Ohm:  40A peak

Input impedance 1kHz Bal. / Unbal.:  20 KΩ  / 33KΩ

350M Damping factor*:  100

350M HP Damping factor*:  200

350M 20th Anniversary Limited Edition Damping factor*:  200

350M MSRP each (usd):  No longer in production

350M HP MSRP each (usd):  No longer in production

350M 20th Anniversary Limited Edition MSRP each (usd):  $113,000 ($226,000 usd per pair) excluding any Duties or VAT

Weight per unit:  118 lbs / 53.5 kg

Shipping weight in custom road case:  148 lbs / 67.2 kg

Dimensions:  19.5” W x 28” D (including connectors) x 9.5” H (including top ventilation)

* : @ 8 Ohm, 1kHz
